QKNEST CNC Cutting Machine Nesting Software

Based on market demand,QK have developed a special customized version of nesting software.Easy to operate, easy to learn, easy connection with ERP system, more user-friendly functions, to meet different needs of different nesting.

• Support oxyfuel, plasma, laser cutting

• Fully automatic multi-plate and multi-part batch nesting,

• Manual nesting

• Batch setting of entry and exit cutting lines

• Import DXF/DWG format graphics

• Output TXT, CNC, DIN, ISO and other code files

• Convert different spline curves to arc lines

• Switch between relative value coordinates and absolute value coordinates

• Mouse-ear addition and chamfering settings

• Find open gaps in various geometric shapes

• Automatically remove duplicate line segments

• Automatically delete the dimensions of the drawings

• Fully automatic simulation

• Calculation of sheet utilization rate, which can be converted into tonnage

• Nesting data visualization

• Cutting and re-nesting of remaining panels

• Multi-point and single-point variable bevel cutting and fixed bevel cutting, custom angle and start and end points

• Tandem cutting, bridging cutting, micro-joint cutting, internal and external contour switching, clockwise and counterclockwise switching

Customer on-site usage:

laser cutting

Bevel cut:

Plasma cut:
